Astronomers used the NASA/ESA/CSA James Webb Space Telescope to image the warm dust around a nearby young star, Fomalhaut, in order to study the first asteroid belt ever seen outside of our Solar System in infrared light. But to their surprise, they found that the dusty structures are much more complex than the asteroid and Kuiper dust belts of our Solar System. Overall, there are three nested belts extending out to 23 billion kilometres from the star – that’s 150 times the distance of Earth from the Sun. The scale of the outermost belt is roughly twice the scale of our Solar System’s Kuiper Belt of small bodies and cold dust beyond Neptune. The inner belts – which had never been seen before – were revealed by Webb for the first time.
The belts encircle the young hot star, which can be seen with the naked eye as the brightest star in the southern constellation Piscis Austrinus. The dusty belts are the debris from collisions of larger bodies, analogous to asteroids and comets, and are frequently described as ‘debris discs’.
“I would describe Fomalhaut as the archetype of debris discs found elsewhere in our galaxy, because it has components similar to those we have in our own planetary system,” said András Gáspár of the University of Arizona in Tucson and lead author of a new paper describing these results. “By looking at the patterns in these rings, we can actually start to make a little sketch of what a planetary system ought to look like – if we could actually take a deep enough picture to see the suspected planets.”
The NASA/ESA Hubble Space Telescope and ESA’s Herschel Space Observatory, as well as the Atacama Large Millimeter/submillimeter Array (ALMA), have previously taken sharp images of the outermost belt. However, none of them found any structure interior to it. The inner belts have been resolved for the first time by Webb in infrared light.
“Where Webb really excels is that we’re able to physically resolve the thermal glow from dust in those inner regions. So you can see inner belts that we could never see before,” said Schuyler Wolff, another member of the team at the University of Arizona.
Hubble, ALMA, and Webb are tag-teaming to assemble a holistic view of the debris discs around a number of stars. “With Hubble and ALMA, we were able to image a bunch of Kuiper Belt analogues, and we’ve learned loads about how outer discs form and evolve,” said Wolff. “But we need Webb to allow us to image a dozen or so asteroid belts elsewhere. We can learn just as much about the inner warm regions of these discs as Hubble and ALMA taught us about the colder outer regions.”
These belts are most likely shaped by the gravitational forces produced by unseen planets. Similarly, inside our Solar System Jupiter corrals the asteroid belt, the inner edge of the Kuiper Belt is sculpted by Neptune, and the outer edge could be shepherded by as-yet-unseen bodies beyond it. As Webb images more systems, we will learn about the configurations of their planets.
Fomalhaut’s dust ring was discovered in 1983 in observations made by NASA’s Infrared Astronomical Satellite (IRAS). The existence of the ring has also been inferred from previous and longer-wavelength observations using submillimetre telescopes on Maunakea, Hawai‘i, NASA’s Spitzer Space Telescope, and Caltech’s Submillimeter Observatory.
“The belts around Fomalhaut are kind of a mystery novel: Where are the planets?” said George Rieke, another team member and US science lead for Webb’s innovative Mid-Infrared Instrument (MIRI), which made these observations. “I think it’s not a very big leap to say there’s probably a really interesting planetary system around the star.”
“We definitely didn’t expect the more complex structure with the second intermediate belt and then the broader asteroid belt,” added Wolff. “That structure is very exciting because any time an astronomer sees a gap and rings in a disc, they say, ‘There could be an embedded planet shaping the rings!’”
Webb also imaged what Gáspár dubs ‘the great dust cloud’, which may be evidence for a collision occurring in the outer ring between two protoplanetary bodies. This is a different feature from the suspected planet first seen inside the outer ring by Hubble in 2008. Subsequent Hubble observations showed that by 2014 the object had vanished. A plausible interpretation is that this newly discovered feature, like the earlier one, is an expanding cloud of very fine dust particles from two icy bodies that smashed into each other.
The idea of a protoplanetary disc around a star goes back to the late 1700s when astronomers Immanuel Kant and Pierre-Simon Laplace independently developed the theory that the Sun and planets formed from a rotating gas cloud that collapsed and flattened under gravity. Debris discs develop later, following the formation of planets and dispersal of the primordial gas in the systems. They show that small bodies like asteroids are colliding catastrophically and pulverising their surfaces into huge clouds of dust and other debris. Observations of dust provide unique clues to the structure of an exoplanetary system, reaching down to Earth-sized planets and even asteroids, which are much too small to see individually.
“This very exciting result highlights the unique power of MIRI to study the structures carved by planets in the innermost regions of circumstellar discs,” adds Gillian Wright, European principal investigator for MIRI and Director of the UK Astronomy Technology Centre (UKATC).
